Earthing & Bonding VR training.
Train workers to apply, verify and remove circuit-main earths and equipotential bonding correctly so an isolated circuit stays safe to touch.
Earthing & Bonding VR training
DrillXR Earthing and Bonding trains workers to make an isolated circuit genuinely safe to touch, because isolation alone does not. The simulation reproduces the hazards that earthing and bonding exist to control: dangerous touch and step potential on an unbonded structure, back-feed or induced voltage appearing on a circuit assumed dead, an earth applied to the wrong point or to a circuit that was never proved dead, and the earth left in place when the circuit is restored. Inside the headset the worker confirms the circuit is isolated and proved dead, selects the correct earthing and bonding equipment for the rating, applies the earth to a proven dead point in the right order, verifies continuity and equipotential bonding, and removes the earths in sequence with a record before restoration. The discipline of earth-only-what-you-have-proved is what the headset is built to instil.
Earthing is the control that catches what energy isolation misses, and India's framework treats it as integral to safe electrical work. The Electricity Act 2003 and the Central Electricity Authority safety regulations set the duties for working on electrical installations, the Factories Act 1948 covers the safe operation and maintenance of electrical plant, and OISD earthing guidance shapes practice for petroleum installations. The dangerous error is rarely conceptual; it is an earth clamped to an unproven point, a bonding lead left off a structure, or an earth forgotten before re-energisation. None of those are trained out by a diagram on a wall. DrillXR lets a worker apply, verify and remove earths in the headset, and feel the consequence of a back-fed conductor or a missed bond, so the habit holds when a real circuit is in front of them.
Why train earthing & bonding in VR
Earthing failures are about sequence and verification, not theory, and that is exactly what a classroom cannot drill. A worker can explain why a circuit needs earthing and still clamp an earth to a point that was never proved dead, or leave a bonding lead off because the structure "looked" connected. VR makes the sequence physical: the trainee proves the conductor dead, selects rated equipment, applies the earth to the proven point in the correct order, and verifies continuity, with the simulation revealing the danger when an unbonded structure carries touch potential or a back-fed circuit bites. Induced voltage and step potential, the hazards people cannot see, can be modelled and made consequential in the headset. Demonstrating a genuinely back-fed or unbonded circuit to a learner on real plant is unthinkable; DrillXR delivers the same lesson with no exposure, which is what changes behaviour.
Inside a earthing & bonding session
The session begins with a circuit that the trainee has been told is isolated. Their first duty is not to trust that but to confirm isolation and prove the circuit dead, testing their detector on a known live source before and after. They select earthing and bonding equipment rated for the circuit rather than whatever is to hand. They apply the earth to a proven dead point and in the correct order, and where a structure is present they apply equipotential bonding; clamp to an unproven point and the simulation demonstrates the consequence. They verify continuity and confirm the bonding is effective, establishing the equipotential zone. With work notionally complete, they remove the earths in the correct sequence and record the removal before restoration. Leaving an earth applied at restoration, or skipping the prove-dead step, is captured against the score.
Scoring & certification
Each attempt is scored across the procedure: circuit confirmed isolated and proved dead, correct equipment selected, earth applied to a proven dead point in order, continuity and bonding verified, and earths removed in sequence and recorded. The decisive failures are logged explicitly, an earth applied to an unproven point, a missed bond on a structure, a back-feed not accounted for, or an earth left applied before restoration. Per-step weighting produces an overall competency outcome, and a passing run issues a dated certificate against the worker's record. Results stream over xAPI and SCORM to the LMS and the DrillXR compliance dashboard, where a safety officer can confirm only verified-competent staff apply earths and can evidence that earthing-and-bonding competence to an electrical inspector or auditor.
Deployment on your site
Earthing and Bonding runs on Meta Quest, Pico and PC-VR and launches in kiosk mode, so a headset in the maintenance or training bay boots straight into the module for the next worker with no setup. The scenario is configurable to the site: the circuit ratings, the earthing points and equipment available, the structures requiring bonding, and the site earthing and permit-to-work procedure can be mirrored so the training matches the installations crews actually work on. A fleet of headsets is managed from one console with completion data feeding the central dashboard. For power, oil and gas and chemicals operators, this delivers consistent earthing-and-bonding competence across sites and proves, per worker, that the prove-before-you-earth and remove-before-you-restore steps are being trained and assessed.
Explore all VR safety training, see how it adapts to your industry, or read whether VR is effective for safety training.
Hazards it reproduces
- touch and step potential on an unbonded structure
- back-feed or induced voltage on a circuit assumed dead
- earth applied to the wrong point or to a still-live circuit
- earth left applied before re-energisation
The scored procedure
- 01Confirm the circuit is isolated and proved dead
- 02Select the correct earthing and bonding equipment
- 03Apply the earth to a proven dead point in the right order
- 04Verify continuity and equipotential bonding
- 05Remove earths in sequence and record before restoration
Compliance mapping
Earthing & Bonding training by industry & location
Tuned to sector hazards and local regulation. Explore the combinations most relevant to this module.
Earthing & Bonding FAQs
What does the Earthing & Bonding VR module cover?
Train workers to apply, verify and remove circuit-main earths and equipotential bonding correctly so an isolated circuit stays safe to touch.
Which hazards does it simulate?
touch and step potential on an unbonded structure; back-feed or induced voltage on a circuit assumed dead; earth applied to the wrong point or to a still-live circuit; earth left applied before re-energisation.
Is the earthing & bonding training assessed?
Yes. Every step is scored and timed, with pass thresholds that trigger certificates and feed the compliance dashboard.
Which standards does it map to?
Electricity Act 2003 with Central Electricity Authority (Measures relating to Safety and Electric Supply) Regulations 2010; Factories Act 1948 (safe operation and maintenance of electrical plant); OISD guidance on electrical earthing for petroleum installations.
