Industrial Radiography & Radiation Safety VR training.
Drill source handling, cordon control and emergency response for gamma and X-ray radiography so exposure discipline is built before anyone enters a hot bay.
Industrial Radiography & Radiation Safety VR training
DrillXR Industrial Radiography and Radiation Safety puts a radiographer through the source handling, cordon control and emergency response of gamma and X-ray non-destructive testing, where an invisible hazard can deliver a serious dose in seconds. The simulation reproduces the failures that cause radiography overexposures: working in or near an unshielded beam, a gamma source that sticks or detaches in the exposed position rather than returning to its shielded container, a controlled area whose cordon is inadequate or breached by an untrained person, and loss of control or accountability of the radioactive source itself. Inside the headset the trainee verifies the work permit, the source and the survey-meter calibration, establishes and barriers the controlled area out to the dose-rate boundary, conducts the exposure from a safe position while monitoring dose, confirms the source has fully returned and surveys the area, and responds correctly to a stuck source or an alarm while always accounting for the source. The discipline is survey-first, never assume the source is safe.
Radiography is among the most tightly controlled activities in Indian industry because the source is lethal and invisible. The Atomic Energy (Radiation Protection) Rules 2004, made under the Atomic Energy Act 1962, govern the safe use of radiation sources, the Atomic Energy Regulatory Board sets the regulatory requirements and licensing for industrial radiography and the role of the Radiological Safety Officer, and every operator runs a radiation protection programme with an RPO-supervised standard operating procedure. The classic incident is not ignorance of the rules but a shortcut under schedule pressure: an unverified survey-meter, a source assumed returned that was actually stuck, or a cordon that someone walked through. A classroom cannot let a radiographer experience a stuck-source emergency; DrillXR lets the trainee work the survey, the cordon and the stuck-source response on a virtual site where the only cost of a mistake is a lower score.
Why train industrial radiography & radiation safety in VR
Radiation safety is uniquely hard to train because the hazard is invisible, gives no sensory warning, and a real mistake can be catastrophic, so practice on a live source is unthinkable. A radiographer can recite dose limits and still walk toward a source they assumed had returned. Immersive VR makes the invisible visible: the simulation renders the dose field and the alarm, lets the trainee see the survey meter respond, and plays out the consequence of entering an unshielded beam or breaching the cordon, all without a single fibre of real exposure. They practise verifying the meter, establishing the controlled area, monitoring dose, and confirming source return as rehearsed actions, and they work a stuck-source emergency, the scenario that kills, in safety. You cannot stage a real radiography overexposure to teach someone; DrillXR reproduces the source behaviour, the dose field and the emergency faithfully, which is why survey-first discipline holds where a briefing fails.
Inside a industrial radiography & radiation safety session
The session opens at a virtual radiography site with an exposure to make. The trainee first verifies the work permit, checks the source and confirms the survey meter is calibrated and responding, rather than assuming the equipment is good. They establish and barrier the controlled area out to the dose-rate boundary, accounting for all personnel before anything is exposed; a cordon set too tight or a person left inside it costs against the score. They conduct the exposure from a safe position and monitor dose throughout. The decisive sequence comes at the end: the trainee must confirm the source has fully returned to its shielded position and survey the area to prove it, rather than approaching on assumption. The scenario introduces a stuck source and an alarm, and the trainee must respond correctly, retreat, raise the emergency, and account for the source, rather than walking toward it. Approaching an unconfirmed source or breaching the cordon registers as the overexposure it would be.
Scoring & certification
Every run is scored across the procedure: permit, source and survey-meter calibration verified, controlled area established and barriered, exposure conducted from a safe position with dose monitored, source return confirmed and the area surveyed, and a stuck source or alarm responded to with the source accounted for. The decisive failures are captured individually, an unverified meter, a breached cordon, an approach to an unconfirmed source, and above all a wrong response to a stuck source, so an assessor sees the precise lapse rather than a bare result. Per-step weighting produces an overall competency outcome, and a passing run issues a dated certificate against the radiographer's record. Results flow over xAPI and SCORM to the LMS and the DrillXR compliance dashboard, where an RPO can confirm a radiographer is competent before authorising live work and can evidence that competence to an AERB inspection.
Deployment on your site
Industrial Radiography and Radiation Safety runs on Meta Quest, Pico and PC-VR and launches in kiosk mode, so a headset at the site training point boots straight into the module for the next radiographer with no setup. The scenario is configurable to the operation: the source and exposure-device types in use, the site geometry and the dose-rate boundary, the survey-meter and dosimetry equipment, the permit format, and the radiation protection programme and RPO-supervised standard operating procedure can be mirrored so the training matches how exposures are genuinely controlled. A fleet of headsets is managed from one console with completion data feeding the central dashboard. For oil and gas, power and steel operators running non-destructive testing across sites and shifts, this delivers consistent, auditable radiography competence without ever exposing a trainee to a live radioactive source.
Explore all VR safety training, see how it adapts to your industry, or read whether VR is effective for safety training.
Hazards it reproduces
- unshielded exposure to ionising radiation
- a source stuck or detached in the exposure position
- an inadequate or breached cordon
- loss of control or accountability of the radioactive source
The scored procedure
- 01Verify the work permit, source and survey-meter calibration
- 02Establish and barrier the controlled area to the dose-rate boundary
- 03Conduct the exposure from a safe position and monitor dose
- 04Confirm the source has fully returned and survey the area
- 05Respond to a stuck source or alarm and account for the source
Compliance mapping
Industrial Radiography & Radiation Safety FAQs
What does the Industrial Radiography & Radiation Safety VR module cover?
Drill source handling, cordon control and emergency response for gamma and X-ray radiography so exposure discipline is built before anyone enters a hot bay.
Which hazards does it simulate?
unshielded exposure to ionising radiation; a source stuck or detached in the exposure position; an inadequate or breached cordon; loss of control or accountability of the radioactive source.
Is the industrial radiography & radiation safety training assessed?
Yes. Every step is scored and timed, with pass thresholds that trigger certificates and feed the compliance dashboard.
Which standards does it map to?
Atomic Energy (Radiation Protection) Rules 2004 under the Atomic Energy Act 1962; AERB regulatory requirements and licensing for industrial radiography; site radiation protection programme and RPO-supervised standard operating procedure.
